Description
The new STP 60-US solar inverter is an innovative global solution for commercial and utility PV systems. It combines the advantages of decentralized system layouts with the benefits of a centralized inverter design in a solution that brings together the best of both worlds. High efficiency, flexible system design, easy installation, simple commissioning and low maintenance requirements help lower operating costs for the entire plant.
Input (DC)
- Max. input voltage: 1000 V
- MPP voltage range: 570 V – 800 V @400 Vac, 685 V – 800 V @480 Vac
- Min. input voltage: 565 V @400 Vac, 680 V @480 Vac
- Max. input current / short-circuit current: 110 A / 150 A
- Number of independent MPP inputs / strings per MPP input: 1/1 (split up by external PV array junction box)
Output (AC)
- Rated power at nominal voltage: 60,000 W
- Max. apparent AC power: 60,000 VA
- Nominal AC voltage: 3 / PE, 400 V – 480 V, +/-10 %
- Nominal AC voltage range: 400 V – 480 V
AC power frequency / range: 50 Hz / 60 Hz +/-10 % - Rated power frequency / rated grid voltage: 50 Hz, 60 Hz / 400 V, 480 V
- Max. output current: 3 x 87 A
- Power factor at rated power/displacement power factor adjustable: 1/0.8 lagging … 0.8 leading
- Feed-in phases / connection phases: 3 / 3
Efficiency
- Max. efficiency / European weighted efficiency / CEC: 98.8 % / 98.0 % / 98.5 %
